Electron beam machines

The reliable EB high-tech machines for your production!

Electron beam welding and drilling technology was introduced to industry many years ago as a reliable means of fabrication. The layout of the type of machine most suitable for you depends on your requirements and applications. Together with you, we will come up with the machine design that matches your tasks. Steigerwald Strahltechnik is only too happy to pass on its decades of expertise to you.

Within the Global Beam Technologies AG, Steigerwald Strahltechnik GmbH is your expert partner for

Electron beam chamber machines for universal fabrication
EB small chamber machines for fabricating a larger number of items
Electron beam drilling/perforating machines, when lots of holes are involved
Electron strip welding machines for bi- or tri-metal strip productions
Electron beam generators

Electron beam welding and drilling technology

Summary

Electron beam chamber machines: Series EBOCAM^®, EBOMOVE & EBOFLEX
Electron beam drilling/perforating machines: EBOPULS series
Electron beam strip welding machines: EBOCONT^® series
Special EB machines according to customer requirements
Workpiece movements: Rotary devices, tilting devices
Tools
Auxiliary equipment
Accessories
Replacement and wearing parts for these product lines
Electron beam generators:
External generators EBOGEN with 150 kV & 60 kV
Internal mobile generators with 60 kV

Detailed production data

Mains supply: phase current 3 x 400 V ± 10 %, 50 Hz, PEN (if necessary, a mains supply transformer must be connected between the mains supply at the customer and our machinery)
Lightening earth: < 3 Ohm, 35 mm²
Input power and required power depends on the machine model (electron beam generator power, drive, pump set, ...)
Compressed air: ≥ 6 bar
Cooling water: temperature max. 15 °C, pressure 3 to 4 bar
Ambient temperature +12 °C to +35 °C
Relative humidity, not condensing max. 70 %
Avoid electromagnetic fields near the machinery
Vibration-free installation position (normal factory conditions are sufficient)
Floor loading: max. 16 daN/cm²

Electron beam systems are the reliable high-tech processes for your production!

This type of electron beam machine is a universal design for tackling a wide range of welding jobs. The entire EBOCAM® system is modular in construction, both mechanically and electrically.

New designs of modularly constructed electron beam machines with an EB generator that can be moved inside for processing large-scale components.

EB drilling proves much more economical when processing work pieces requiring a large number of drilled holes on each component. Some typical examples where electron beam perforation is applied...
